便携式测厚仪PTG8

材料 超声波 可移植的

PTG8是量程表的顶部，具有测量所需的所有特性和功能，具有精度，几乎任何材料的材料厚度。具有用户自定义显示，用户可以选择查看读数、统计信息、柱状图最高值(Hi);最低(Lo);和average (x);阅读或运行图表;最近20个读数的趋势图。在扫描模式下，读数可以在大表面积上以16Hz(每秒16个读数)的速率进行。当换能器从表面抬起时，显示平均、最低和最高厚度值。校准选项PTG8允许用户存储到内存中多达三个校准。一旦保存，用户可以选择校准，而无需重新校准量规，非常适合测量各种材料或厚度的用户。 Using the gauge’s alpha-numeric function, calibration memories can be re-named to suit the calibration setting. Display Modes The PTG8 has user definable upper and lower limits with audible and visual pass/fail warnings. Limits can be set for individual readings or for each batch. If a measurement is taken which falls outside set limits, the reading value and the limit icon turns red, the red LED flashes and the alarm beeps. The PTG8 has Differential Mode; once a user defined nominal thickness value is set, the gauge displays the measured thickness together with the variation from the set nominal value thus indicating areas of the material which are thinner or thicker than expected.
