Hydraulic fittingSJE
flange
swivel
添加到收藏夹”
Compare this product
Characteristics
- Applications
- hydraulic
- Attachment
- flange
- 其他特征
- swivel
- Diameter
-
5 mm, 6 mm, 8 mm, 10 mm, 12 mm (0.197 in)
- Operating pressure
-
6 bar, 16 bar, 40 bar (87.02 psi)
Description
Series SJE is constructed from steel (42CrMo4) or stainless steel (1.4571) and has a PTFE-compound seal. Series SJE features built-in ball guiding tracks which are similar to ball bearings. It offers swiveling and rotating movements with a low speed. Series SJE has a maximum pressure of 40 bar for steel bis DN 300, 16 bar for steel DN 350, 16 bar for stainless steel bis DN 350 and 6 bar for stainless steel DN 300. It operates at a minimum temperature of -50°C and a maximum temperature of 225 °C. It ranges in size from DN125 to DN700 (5"-28").
Catalogs
Series SJE
7
Pages
Product Guide
24
Pages
